Industry Gantry CNC Plasma Cutter for Sheet Metal Cutting
- Model: CP-2060
- Working Size: 2000*6000mm
- Plasma Source: 120A (Optional 63/100/160/200/300/400A)
- Cutting Thickness: 1-20mm by plasma, 1-200mm by Flame
- Availability: Production after order confirmation (Preorder)
- Payment Method: Bank Transfer (T/T), Trade Assurance
- Standard - Meeting CE Standards in Terms of Quality & Safety
- Warranting - One (1) Year Limited Warranty for Entire Machine
The industrial gantry CNC plasma cutter offers precise and efficient cutting for various sheet metals, including carbon steel, stainless steel, and aluminum. Its sturdy gantry design combined with advanced CNC control delivers high accuracy and speed, making it ideal for heavy industries like steel fabrication, shipbuilding, and automotive manufacturing. With automatic torch height control and programmable cutting paths, this machine ensures clean cuts and improved productivity for large-scale metal processing.
Features of Industry Gantry CNC Plasma Cutter for Sheet Metal Cutting
- The frame is constructed from carbon steel using welded fabrication and undergoes full annealing treatment, resulting in high structural precision and low inertia. The XYZ axes are machined with strict accuracy to prevent any deformation during operation.
- The transmission system features a precision-engineered rack and specialized reducer, combined with high-quality cables sourced from Germany, ensuring exceptional motion accuracy and stability.
- The drive system is powered by an American chip controller with dual motor drives and Panasonic servo motors as standard. Alternatively, Inovance servo motors or high-precision stepper motors are available, delivering strong AC torque to maintain smooth performance even at high speeds.
- Equipped with a high-accuracy CNC controller supporting both English and Chinese interfaces, the machine also includes an automatic torch height control (THC) system for optimized cutting quality.
- Available machine size options include:
Model A40120: 4 meters by 12 meters (also available in 6m, 8m, and 10m lengths)
Model 30120: 3 meters by 12 meters (also offered in 6m, 8m, and 10m lengths)
Specification of Industry Gantry CNC Plasma Cutter for Sheet Metal Cutting
| Parameter | Details |
|---|---|
| Cutting Methods | Plasma and Flame Cutting |
| Machine Dimensions (L×W) | 8000 mm × 3650 mm |
| Maximum Cutting Area (X×Y) | 2000 mm × 6000 mm |
| Applicable Materials | All metal sheets, including mild and high carbon steel |
| Cutting Thickness | Plasma: depends on power source; Flame: 6–200 mm |
| Torch Lift Stroke | ≤ 170 mm |
| Maximum Travel Speed | 8000 mm/min |
| Positioning Accuracy | ≤ 0.05 mm |
| CNC Controller | FangLing F2300B |
| Electrical Components | Schneider Electric (France) |
| Auto Height Control | FL1621 THC System |
| Servo Motors & Drivers | Panasonic (Japan) |
| Drive System | Dual-side motor drive |
| Gearbox Type | APKE planetary reducer |
| Drive Mechanism | Rack and pinion |
| Gas Pressure (Plasma) | 0.4 – 0.7 MPa |
| X, Y Axis Rails | High-quality rack & pinion with 24kg linear rails |
| Power Supply | 220V / 380V (optional) |
| Cutting Gases | Plasma: Compressed air; Flame: Oxygen + Acetylene or Propane |
| Gas Pressures | Oxygen: 0.5 MPa; Fuel Gas: 0.1 MPa |
| Graphic Input Method | USB |
| Supported File Types | AutoCAD DXF, DWG, CAM, NC files |
| Nesting Software | FastCAM |
| Included Torches | 1 Plasma torch set, 1 Flame torch set |
| Consumables Provided | 10 Plasma nozzle sets, 3 Flame nozzle sets |
| Packaging Dimensions (L×W×H) | 3650 mm × 1600 mm × 1580 mm |
| Weight | 2500KGS |
Application of Industry Gantry CNC Plasma Cutter for Sheet Metal Cutting
The industrial gantry CNC plasma cutting machine is widely utilized in numerous heavy-duty industries such as steel structure fabrication, shipbuilding, automotive manufacturing, construction equipment production, industrial machinery manufacturing, metal fabrication shops, and heavy engineering projects. It is especially valued in sectors requiring precise, high-speed cutting of large metal sheets and plates.
This CNC plasma cutter is engineered to process a diverse range of conductive metals including carbon steel, mild steel, high carbon steel, stainless steel, aluminum alloys, galvanized steel, copper, brass, and other metal sheets. Its versatility allows it to efficiently cut materials of varying thicknesses—from thin gauge metals used in industrial enclosures and panels to thick structural steel plates applied in bridges, ships, and heavy machinery.
With advanced features such as programmable cutting paths, automatic torch height control (THC), and high-precision positioning, the gantry plasma cutter delivers clean, accurate cuts with minimal dross, ideal for metal fabrication, sheet metal cutting, plate cutting, industrial metal processing, and custom metal part manufacturing. It supports complex shapes including straight lines, curves, and intricate designs, making it indispensable for industries focused on precision engineering, metalworking, and fabrication services.
